Goel Impex, your trusted partner in advanced laboratory equipment, brings you a superior range of Benchtop Lab Reactors designed to meet the demanding needs of chemical synthesis, pharmaceutical research, and industrial applications. Each benchtop reactor is built with precision and engineered for efficiency, versatility, and reliable performance, providing an ideal solution for small-scale reactions and process development.
As a leading Benchtop Glass Reactor Manufacturer, we offer a comprehensive selection of standard laboratory reactors and glass vessels to support diverse research requirements. Alongside our standard models, we also specialize in designing and fabricating custom Lab Glass Reactors that align perfectly with your operational needs. Whether you share a drawing, technical specifications, or a reference image, our team can develop a Benchtop Reactor System tailored to your exact requirements.
Our team of skilled engineers ensures every Lab Reactor is developed with exceptional precision, durability, and performance. If you are seeking a Lab Glass Reactor Manufacturer, Benchtop Glass Reactor Manufacturer, or Lab Reactors Manufacturers & Suppliers offering fully customized solutions, Goel Impex is here to assist.
For technical guidance, product customization, or support, please contact us at anshul@goelequipments.com.
• Glass Benchtop Reactors manufactured using high-quality German raw materials.
• Compact Benchtop Lab Reactor system designed to fit most standard laboratory fume hoods.
• Equipped with a stirrer featuring mechanical seal, stuffing box, or magnetic seal options.
• Skid-mounted design with quick-release clamps for easy installation and convenient removal of glassware.
• Fully suitable for vacuum operations to support a wide range of laboratory applications.
• Flush bottom outlet engineered for minimum dead volume and maximum efficiency.
• Overhead stirrer geared motor integrated with a digital speed controller and display.
• Clear measurement markings on the Glass Benchtop Reactor vessel for accurate volume monitoring.
• Interchangeable stirrer options available: anchor, propeller, or turbine for versatile mixing needs.
• Digital temperature indicator included for precise monitoring of reaction conditions.
Single Wall, Double Wall or Tripple Wall Glass Reactors
Temperature:
– 50°C up to 180 °C
Pressure:
Full vacuum up to 0.5 bar
Capacities:
100 ml up to 10 L
Hot Water/Oil Circulator, Chiller, Heating/Cooling System, Vacuum Pump, pH Probe with Transmitter, Pressure Gauge.
|
Unit |
Reactor |
Gear Motor With Inbuilt Digital Indicator |
Addition Funnel |
Condenser Length |
L x B x H |
|
LJR 1L |
1 Ltr. (100DN) |
Speed 40 – 400 RPM |
250ml |
200mm |
250x250x900 |
|
LJR 2L |
2 Ltr. (100DN) |
Speed 40 – 400 RPM |
500ml |
300mm |
250x250x1350 |
|
LJR 3L |
3 Ltr. (100DN) |
Speed 40 – 400 RPM |
500ml |
400mm |
250x250x1450 |
|
LJR 5L |
5 Ltr. (150DN) |
Speed 40 – 400 RPM |
1000ml |
500mm |
350x350x1450 |
|
LJR 10L |
10 Ltr. (200DN) |
Speed 40 – 400 RPM |
2000ml |
600mm |
400x400x1700 |
