Glass Flask

Laboratory Glassware

All What You Need To Know Laboratory Glassware

Glass Flask

5171 GLASS FLASKS BOILING, FLORENCE, FLAT BOTTOM
Cat. Ref. Capacity Ml. Approx O.D. mm Hight. mm Approx. Neck O.D. mm Qty
per case
5171/10
 25 42 90 20 48
5171/13
 50 51 95 24 48
5171/15
 100 64 105 24 48
5171/17
 150 75 132 28 36
5171/21
 250 85 140 34 48
5171/22
 300 87 160 24 24
5171/24
 500 105 170 34 24
5171/28
 1000 131 200 40 12
5171/29
 2000 167 250 50 8
5171/30
 3000 185 300 50 2
5171/32
 5000 223 340 60 4
5171/33
 6000 236 340 65 1
5171/35
 10000 285 400 65 1
5171/40
 20000 350 505 75 1

5211 GLASS FLASKS BOILING, FLAT BOTTOM, SHORT NECK, INTERCHANGEBLE JOINT.

Cat. Ref. Capacity Ml. I/C Joint Approx. Ht. mm Qty per case
5211/17 150 B24 115 6
5211/21 250 B24 130 6
5211/24 500 B24 148 6



5371 GLASS FLASKS BOILING, ROUND BOTTOM

Cat. Ref. Capacity Ml. Approx O.D. mm Hight. mm Approx. Neck O.D. mm Qty per case
5371/10
 25 42 90 20 48
5371/13
 50 51 95 24 48
5371/15
 100 64 110 24 48
5371/17
 150 75 137 28 36
5371/21
 250 85 145 34 48
5371/24
 500 105 178 34 24
5371/28
 1000 131 212 40 12
5371/29
 2000 167 260 50 8
5371/30
 3000 185 310 50 2
5371/32
 5000 223 350 60 4
5371/33
 6000 236 350 65 1
5371/35
 10000 285 420 65 1
5371/40
 20000 350 505 75 1

5441 GLASS FLASKS (VESSELS) REACTION, WIDE MOUTH, FLAT FLANGE 100mm I.D., 150 mm O.D.

Cat. Ref. Capacity Ml. Hight. mm Qty per case
5441/28
 1000 170 2
5441/29
 2000 205 2
5441/32
 5000 260 1
5441/35
 10000 320 1
5441/40
 20000 400 1

5442 LIDS FOR GLASS FLASKS REACTION CAT NO.5441 FLAT FLANGE AND INTERCHANGEABLE JOINT

Cat. Ref. Cap Ml. Centre Parallel Qty per case
5442/1924 19/26×3,24/29 19/26 19/26 2
5442/1914 19/26,14/23 x 3, 29/32 19/26 19/26 2
5442/2914 29/32×2,14/23×3 19/26 14/23 2
5442/1934 19/26 x 4,34/35 19/26 19/26 2
5442/2434 19/26 x 3,24/29,34/35 24/29 24/29 2

5491 GLASS FLASKS BOILING, ROUND BOTTOM, SHORT NECK WITH INTERCHANGABLE JOINT.

Cat. Ref. Capacity Ml. Joint Approx. O.D. mm Approx. Ht. mm Qty per case
5491/13
 50 19/26 51 95 6
5491/15
 100 24/29 64 120 12
5491/21
 250 24/29 85 140 12
5491/24
 500 24/29 105 160 8
5491/28
 1000 24/29 131 188 8
5491/29
 2000 24/29 167 228 2
5491/30
 3000 24/29 185 255 2
5491/32
 5000 45/40 223 300 1
5491/35
 10000 55/44 285 385 1
5491/40
 20000 55/44 350 435 1

5492 GLASS FLASKS ROUND BOTTOM, TWO NECKS, CENTRE NECK AND ONE ANGLED SIDE NECK INTERCHANGEBLE JOINT.

Cat. Ref. Capacity Ml. Interchangeable
Joint Size
Center Neck Side Neck		 Approx. Ht. mm Qty per case
5492/15-A
 100 24/29 14/23 120 12
5492/15-B
 100 24/29 19/26 120 12
5492/21-A
 250 24/29 14/23 140 12
5492/21-B
 250 24/29 19/26 140 12
5492/24-A
 500 24/29 14/23 160 8
5492/24-B
 500 24/29 19/26 160 8
5492/28-A
 1000 24/29 14/23 190 8
5492/28-B
 1000 24/29 19/26 190 8
5492/29-A
 2000 24/29 14/23 230 2
5492/29-B
 2000 24/29 19/26 230 2
5492/29-C
 2000 34/35 19/26 230 2
5492/30
 3000 34/35 19/26 255 2
5492/32
 5000 34/35 19/26 300 1
5492/35
 10000 55/44 24/29 385 1
5492/40
 20000 55/44 24/29 435 1

Joint sizes to be indicated while placing orders.

5493 GLASS FLASKS ROUND BOTTOM, TWO NECKS, CENTER NECK AND ONE PARALLEL SIDE NECK WITH INTERCHANGEBLE JOINT.

Cat. Ref. Capacity Ml. Interchangeable
Joint Size
Center Neck Side Neck		 Approx. Ht. mm Qty
per case
5493/15-A
 100 24/29 14/23 120 12
5493/15-B
 100 24/29 19/26 120 12
5493/21-A
 250 24/29 14/23 140 12
5493/21-B
 250 24/29 19/26 140 12
5493/24-A
 500 24/29 14/23 160 8
5493/24-B
 500 24/29 19/26 160 8
5493/28-A
 1000 24/29 14/23 190 8
5493/28-B
 1000 24/29 19/26 190 8
5493/29-A
 2000 24/29 14/23 230 2
5493/29-B
 2000 24/29 19/26 230 2
5493/30
 3000 34/35 19/26 255 2
5493/32
 5000 34/35 19/26 300 1
5493/35
 10000 55/44 24/29 385 1
5493/40
 20000 55/44 24/29 435 1

Joint sizes to be indicated while placing orders.

5494 GLASS FLASKS ROUND BOTTOM, THREE NECKS, CENTER NECK AND TWO ANGLED SIDE NECKS WITH INTERCHANGEBLE JOINT.

Cat. Ref. Capacity Ml. Interchangeable
Joint Size
Center Neck Side Neck		 Approx. Ht. mm Qty
per case
5494/15-A
 100 24/29 14/23 120 12
5494/15-B
 100 24/29 19/26 120 12
5494/21-A
 250 24/29 14/23 140 12
5494/21-B
 250 24/29 19/26 140 12
5494/24-A
 500 24/29 14/23 160 8
5494/24-B
 500 24/29 19/26 160 8
5494/28
 1000 24/29 14/23 190 8
5494/29-A
 2000 24/29 14/23 230 2
5494/29-B
 2000 24/29 19/26 230 2
5494/30
 3000 34/35 19/26 255 2
5494/32
 5000 34/35 19/26 300 1
5494/35
 10000 55/44 24/29 385 1
5494/40
 20000 55/44 24/29 435 1

Joint sizes to be indicated while placing orders.

5495 GLASS FLASKS ROUND BOTTOM, THREE NECKS, CENTER NECK AND TWO PARALLEL SIDE NECKS WITH INTERCHANGEBLE JOINT.

Cat. Ref. Capacity Ml. Interchangeable
Joint Size
Center Neck Side Neck		 Approx. Ht. mm Qty
per case
5495/15-A
 100 24/29 14/23 120 12
5495/15-B
 100 24/29 19/26 120 12
5495/21-A
 250 24/29 14/23 140 12
5495/21-B
 250 24/29 19/26 140 12
5495/24-A
 500 24/29 14/23 160 8
5495/24-B
 500 24/29 19/26 160 8
5495/28
 1000 24/29 14/23 190 8
5495/29-A
 2000 24/29 14/23 230 2
5495/29-B
 2000 24/29 19/26 230 2
5495/30
 3000 34/35 19/26 255 2
5495/32
 5000 34/35 19/26 300 1
5495/35
 10000 55/44 24/29 385 1
5495/40
 20000 55/44 24/29 435 1

Joint sizes to be indicated while placing orders.

5533 GLASS FLASKS CULTURE, HAFFKINE

Cat. Ref. Capacity Ml. Approx OD mm. Hight. mm Qty
per case
5533/30
 3000 241 273 2
5533/31
 4000 245 310 2

5731 GLASS FLASKS DISTILLING, WITH SIDE ARM

Cat. Ref. Capacity Ml. Approx OD mm. Hight. mm Approx. O.D. Neck mm Qty
per case
5731/15
 100 65 210 22 12
5731/16*
 125 68 215 22 20
5731/21
 250 87.5 235 24 20
5731/24
 500 110 258 28 4
5731/28
 1000 138 285 34 4
5731/29
 2000 170 318 40 4

* Specifications as per Institute of Petroleum Std. No. IP123/64

5091 GLASS FLASKS ERLENMEYER, GRADUATED, CONICAL, NARROW MOUTH

Cat. Ref. Capacity Ml. Approx OD mm. Hight. mm Approx. O.D. Neck mm Qty
per case
5091/06
 10 34 60 15 24
5091/10
 25 42 70 21 48
5091/13
 50 51 82 24 48
5091/15
 100 64 105 24 48
5091/17
 150 72 124 30 36
5091/21
 250 85 140 34 48
5091/24
 500 105 176 34 24
5091/28
 1000 131 220 42 12
5091/29
 2000 165 286 48 8
5091/30
 3000 185 325 48 2
5091/32
 5000 220 377 50 4
5091/35
 10000 280 450 60 1

25 ml to 5000 ml Graduated.

5092 GLASS FLASKS ERLENMEYER CONICAL, LONG NECK, WITHOUT RIM

Cat. Ref. Capacity Ml. Approx O.D. mm. Hight. mm Approx. Neck O.D. mm Qty
per case
5092/21
 250 78 154 24 48

Suitable for culture work, designed for cotton plug or metal caps.

5093 GLASS FLASKS CONICAL, WITHOUT RIM

Cat. Ref. Capacity Ml. Approx OD mm. Hight. mm Approx. Neck O.D.mm Qty
per case
5093/26
 750 114 210 34 12

5090 GLASS FLASKS ERLENMEYER, GRADUATED, CONICAL, AMBER WITH NARROW MOUTH

Cat. Ref. Capacity Ml. Approx OD mm. Hight. mm Approx. Neck O.D.mm Qty
per case
5090/15
 100 64 105 24 48
5090/17
 150 72 124 30 36
5090/21
 250 85 140 34 48
5090/24
 500 105 176 34 24
5090/28
 1000 131 220 42 12
5090/29
 2000 165 286 50 12
5090/30
 3000 185 325 50 8
5090/32
 5000 220 377 50 4
5090/35
 10000 280 450 60 1

6111 GLASS FLASKS ERLENMEYER, NARROW MOUTH, INTERCHANGEBLE JOINT.

Cat. Ref. Capacity Ml. Joint Hight. mm Qty
per case
6111/21
 250 24/29 145 12
6111/24
 500 24/29 176 8

6131 GLASS FLASKS ERLENMEYER, CONICAL, NARROW MOUTH, WITH INTERCHANGEABLE STOPPER

Cat. Ref. Capacity Ml. Interchang
eable Joint		 Hight. mm Qty
per case
6131/10
 25 14/15 65 12
6131/13
 50 19/20 85 12
6131/15
 100 24/25 90 12
6131/21
 250 29/25 145 12
6131/24
 500 29/25 176 12

6211 GLASS FLASKS ERLENMEYER, CONICAL, WIDE MOUTH

Cat. Ref. Capacity Ml. Approx O.D. mm. Hight. mm Approx. Neck O.D.mm Qty
per case
6211/15
 100 70 110 34 12
6211/21
 250 85 142 50 12
6211/24
 500 105 175 50 12
6211/28
 1000 130 220 56 12

6451 GLASS FLASKS FILTERING, HEAVY WALL, BOLT NECK WITH TUBULATION

Cat. Ref. Capacity Ml. Approx O.D. mm. Hight. mm Qty
per case

6451/13
50
52
82
16
6451/15
100
68
100
16
6451/21
250
85
165
16
6451/24
500
105
184
12
6451/28
1000
136
250
8
6451/29
2000
168
295
4
6451/32
5000
237
450
1
6451/35*
**10000
220
500
1
6451/40*
**20000
300
560
1

* These flasks are bottle shaped.

6511 GLASS FLASKS IODINE DETERMINATION, INTERCHANGEABLE STOPPER

Cat. Ref. Capacity Ml. Approx. O.D. mm Approx. Ht. mm Joint Qty
per case
6511/15
 100 64 125 24/29 8
6511/21
 250 85 165 24/29 8
6511/24
 500 105 195 24/29 8

6531 GLASS FLASKS KJELDAHL, ROUND BOTTOM, LONG NECK

Cat. Ref. Capacity Ml. Approx O.D. mm. Hight. mm Qty
per case
6531/06
 10 30 180 8
6531/11
 30 40 180 8
6531/15
 100 61 210 12
6531/22
 300 80 298 12
6531/24
 500 97 325 8
6531/27
 800 113 375 8

6541 GLASS FLASKS KJELDAHL, ROUND BOTTOM INTERCHANGEABLE JOINT

Cat. Ref. Capacity Ml. Approx O.D. mm. Hight. mm Joint Qty
per case
6541/24
 500 97 325 24/29 8
6541/27
 800 113 375 24/29 8
DOWNLOAD PDF
