Glass Flask

Laboratory Glassware

All What You Need To Know Laboratory Glassware

Glass Flask

5171 GLASS FLASKS BOILING, FLORENCE, FLAT BOTTOM

Cat. Ref.	Capacity Ml.	Approx O.D. mm	Hight. mm	Approx. Neck O.D. mm	Qty per case
5171/10	25	42	90	20	48
5171/13	50	51	95	24	48
5171/15	100	64	105	24	48
5171/17	150	75	132	28	36
5171/21	250	85	140	34	48
5171/22	300	87	160	24	24
5171/24	500	105	170	34	24
5171/28	1000	131	200	40	12
5171/29	2000	167	250	50	8
5171/30	3000	185	300	50	2
5171/32	5000	223	340	60	4
5171/33	6000	236	340	65	1
5171/35	10000	285	400	65	1
5171/40	20000	350	505	75	1

5211 GLASS FLASKS BOILING, FLAT BOTTOM, SHORT NECK, INTERCHANGEBLE JOINT.

Cat. Ref.	Capacity Ml.	I/C Joint	Approx. Ht. mm	Qty per case
5211/17	150	B24	115	6
5211/21	250	B24	130	6
5211/24	500	B24	148	6

5371 GLASS FLASKS BOILING, ROUND BOTTOM

Cat. Ref.	Capacity Ml.	Approx O.D. mm	Hight. mm	Approx. Neck O.D. mm	Qty per case
5371/10	25	42	90	20	48
5371/13	50	51	95	24	48
5371/15	100	64	110	24	48
5371/17	150	75	137	28	36
5371/21	250	85	145	34	48
5371/24	500	105	178	34	24
5371/28	1000	131	212	40	12
5371/29	2000	167	260	50	8
5371/30	3000	185	310	50	2
5371/32	5000	223	350	60	4
5371/33	6000	236	350	65	1
5371/35	10000	285	420	65	1
5371/40	20000	350	505	75	1

5441 GLASS FLASKS (VESSELS) REACTION, WIDE MOUTH, FLAT FLANGE 100mm I.D., 150 mm O.D.

Cat. Ref.	Capacity Ml.	Hight. mm	Qty per case
5441/28	1000	170	2
5441/29	2000	205	2
5441/32	5000	260	1
5441/35	10000	320	1
5441/40	20000	400	1

5442 LIDS FOR GLASS FLASKS REACTION CAT NO.5441 FLAT FLANGE AND INTERCHANGEABLE JOINT

Cat. Ref.	Cap Ml.	Centre	Parallel	Qty per case
5442/1924	19/26×3,24/29	19/26	19/26	2
5442/1914	19/26,14/23 x 3, 29/32	19/26	19/26	2
5442/2914	29/32×2,14/23×3	19/26	14/23	2
5442/1934	19/26 x 4,34/35	19/26	19/26	2
5442/2434	19/26 x 3,24/29,34/35	24/29	24/29	2

5491 GLASS FLASKS BOILING, ROUND BOTTOM, SHORT NECK WITH INTERCHANGABLE JOINT.

Cat. Ref.	Capacity Ml.	Joint	Approx. O.D. mm	Approx. Ht. mm	Qty per case
5491/13	50	19/26	51	95	6
5491/15	100	24/29	64	120	12
5491/21	250	24/29	85	140	12
5491/24	500	24/29	105	160	8
5491/28	1000	24/29	131	188	8
5491/29	2000	24/29	167	228	2
5491/30	3000	24/29	185	255	2
5491/32	5000	45/40	223	300	1
5491/35	10000	55/44	285	385	1
5491/40	20000	55/44	350	435	1

5492 GLASS FLASKS ROUND BOTTOM, TWO NECKS, CENTRE NECK AND ONE ANGLED SIDE NECK INTERCHANGEBLE JOINT.

Cat. Ref.	Capacity Ml.	Interchangeable Joint Size Center Neck Side Neck	Approx. Ht. mm	Qty per case
5492/15-A	100	24/29 14/23	120	12
5492/15-B	100	24/29 19/26	120	12
5492/21-A	250	24/29 14/23	140	12
5492/21-B	250	24/29 19/26	140	12
5492/24-A	500	24/29 14/23	160	8
5492/24-B	500	24/29 19/26	160	8
5492/28-A	1000	24/29 14/23	190	8
5492/28-B	1000	24/29 19/26	190	8
5492/29-A	2000	24/29 14/23	230	2
5492/29-B	2000	24/29 19/26	230	2
5492/29-C	2000	34/35 19/26	230	2
5492/30	3000	34/35 19/26	255	2
5492/32	5000	34/35 19/26	300	1
5492/35	10000	55/44 24/29	385	1
5492/40	20000	55/44 24/29	435	1

Joint sizes to be indicated while placing orders.

5493 GLASS FLASKS ROUND BOTTOM, TWO NECKS, CENTER NECK AND ONE PARALLEL SIDE NECK WITH INTERCHANGEBLE JOINT.

Cat. Ref.	Capacity Ml.	Interchangeable Joint Size Center Neck Side Neck	Approx. Ht. mm	Qty per case
5493/15-A	100	24/29 14/23	120	12
5493/15-B	100	24/29 19/26	120	12
5493/21-A	250	24/29 14/23	140	12
5493/21-B	250	24/29 19/26	140	12
5493/24-A	500	24/29 14/23	160	8
5493/24-B	500	24/29 19/26	160	8
5493/28-A	1000	24/29 14/23	190	8
5493/28-B	1000	24/29 19/26	190	8
5493/29-A	2000	24/29 14/23	230	2
5493/29-B	2000	24/29 19/26	230	2
5493/30	3000	34/35 19/26	255	2
5493/32	5000	34/35 19/26	300	1
5493/35	10000	55/44 24/29	385	1
5493/40	20000	55/44 24/29	435	1

Joint sizes to be indicated while placing orders.

5494 GLASS FLASKS ROUND BOTTOM, THREE NECKS, CENTER NECK AND TWO ANGLED SIDE NECKS WITH INTERCHANGEBLE JOINT.

Cat. Ref.	Capacity Ml.	Interchangeable Joint Size Center Neck Side Neck	Approx. Ht. mm	Qty per case
5494/15-A	100	24/29 14/23	120	12
5494/15-B	100	24/29 19/26	120	12
5494/21-A	250	24/29 14/23	140	12
5494/21-B	250	24/29 19/26	140	12
5494/24-A	500	24/29 14/23	160	8
5494/24-B	500	24/29 19/26	160	8
5494/28	1000	24/29 14/23	190	8
5494/29-A	2000	24/29 14/23	230	2
5494/29-B	2000	24/29 19/26	230	2
5494/30	3000	34/35 19/26	255	2
5494/32	5000	34/35 19/26	300	1
5494/35	10000	55/44 24/29	385	1
5494/40	20000	55/44 24/29	435	1

Joint sizes to be indicated while placing orders.

5495 GLASS FLASKS ROUND BOTTOM, THREE NECKS, CENTER NECK AND TWO PARALLEL SIDE NECKS WITH INTERCHANGEBLE JOINT.

Cat. Ref.	Capacity Ml.	Interchangeable Joint Size Center Neck Side Neck	Approx. Ht. mm	Qty per case
5495/15-A	100	24/29 14/23	120	12
5495/15-B	100	24/29 19/26	120	12
5495/21-A	250	24/29 14/23	140	12
5495/21-B	250	24/29 19/26	140	12
5495/24-A	500	24/29 14/23	160	8
5495/24-B	500	24/29 19/26	160	8
5495/28	1000	24/29 14/23	190	8
5495/29-A	2000	24/29 14/23	230	2
5495/29-B	2000	24/29 19/26	230	2
5495/30	3000	34/35 19/26	255	2
5495/32	5000	34/35 19/26	300	1
5495/35	10000	55/44 24/29	385	1
5495/40	20000	55/44 24/29	435	1

Joint sizes to be indicated while placing orders.

5533 GLASS FLASKS CULTURE, HAFFKINE

Cat. Ref.	Capacity Ml.	Approx OD mm.	Hight. mm	Qty per case
5533/30	3000	241	273	2
5533/31	4000	245	310	2

5731 GLASS FLASKS DISTILLING, WITH SIDE ARM

Cat. Ref.	Capacity Ml.	Approx OD mm.	Hight. mm	Approx. O.D. Neck mm	Qty per case
5731/15	100	65	210	22	12
5731/16*	125	68	215	22	20
5731/21	250	87.5	235	24	20
5731/24	500	110	258	28	4
5731/28	1000	138	285	34	4
5731/29	2000	170	318	40	4

* Specifications as per Institute of Petroleum Std. No. IP123/64

5091 GLASS FLASKS ERLENMEYER, GRADUATED, CONICAL, NARROW MOUTH

Cat. Ref.	Capacity Ml.	Approx OD mm.	Hight. mm	Approx. O.D. Neck mm	Qty per case
5091/06	10	34	60	15	24
5091/10	25	42	70	21	48
5091/13	50	51	82	24	48
5091/15	100	64	105	24	48
5091/17	150	72	124	30	36
5091/21	250	85	140	34	48
5091/24	500	105	176	34	24
5091/28	1000	131	220	42	12
5091/29	2000	165	286	48	8
5091/30	3000	185	325	48	2
5091/32	5000	220	377	50	4
5091/35	10000	280	450	60	1

25 ml to 5000 ml Graduated.

5092 GLASS FLASKS ERLENMEYER CONICAL, LONG NECK, WITHOUT RIM

Cat. Ref.	Capacity Ml.	Approx O.D. mm.	Hight. mm	Approx. Neck O.D. mm	Qty per case
5092/21	250	78	154	24	48

Suitable for culture work, designed for cotton plug or metal caps.

5093 GLASS FLASKS CONICAL, WITHOUT RIM

Cat. Ref.	Capacity Ml.	Approx OD mm.	Hight. mm	Approx. Neck O.D.mm	Qty per case
5093/26	750	114	210	34	12

5090 GLASS FLASKS ERLENMEYER, GRADUATED, CONICAL, AMBER WITH NARROW MOUTH

Cat. Ref.	Capacity Ml.	Approx OD mm.	Hight. mm	Approx. Neck O.D.mm	Qty per case
5090/15	100	64	105	24	48
5090/17	150	72	124	30	36
5090/21	250	85	140	34	48
5090/24	500	105	176	34	24
5090/28	1000	131	220	42	12
5090/29	2000	165	286	50	12
5090/30	3000	185	325	50	8
5090/32	5000	220	377	50	4
5090/35	10000	280	450	60	1

6111 GLASS FLASKS ERLENMEYER, NARROW MOUTH, INTERCHANGEBLE JOINT.

Cat. Ref.	Capacity Ml.	Joint	Hight. mm	Qty per case
6111/21	250	24/29	145	12
6111/24	500	24/29	176	8

6131 GLASS FLASKS ERLENMEYER, CONICAL, NARROW MOUTH, WITH INTERCHANGEABLE STOPPER

Cat. Ref.	Capacity Ml.	Interchang eable Joint	Hight. mm	Qty per case
6131/10	25	14/15	65	12
6131/13	50	19/20	85	12
6131/15	100	24/25	90	12
6131/21	250	29/25	145	12
6131/24	500	29/25	176	12

6211 GLASS FLASKS ERLENMEYER, CONICAL, WIDE MOUTH

Cat. Ref.	Capacity Ml.	Approx O.D. mm.	Hight. mm	Approx. Neck O.D.mm	Qty per case
6211/15	100	70	110	34	12
6211/21	250	85	142	50	12
6211/24	500	105	175	50	12
6211/28	1000	130	220	56	12

6451 GLASS FLASKS FILTERING, HEAVY WALL, BOLT NECK WITH TUBULATION

Cat. Ref.	Capacity Ml.	Approx O.D. mm.	Hight. mm	Qty per case
6451/13	50	52	82	16
6451/15	100	68	100	16
6451/21	250	85	165	16
6451/24	500	105	184	12
6451/28	1000	136	250	8
6451/29	2000	168	295	4
6451/32	5000	237	450	1
6451/35*	**10000	220	500	1
6451/40*	**20000	300	560	1

* These flasks are bottle shaped.

6511 GLASS FLASKS IODINE DETERMINATION, INTERCHANGEABLE STOPPER

Cat. Ref.	Capacity Ml.	Approx. O.D. mm	Approx. Ht. mm	Joint	Qty per case
6511/15	100	64	125	24/29	8
6511/21	250	85	165	24/29	8
6511/24	500	105	195	24/29	8

6531 GLASS FLASKS KJELDAHL, ROUND BOTTOM, LONG NECK

Cat. Ref.	Capacity Ml.	Approx O.D. mm.	Hight. mm	Qty per case
6531/06	10	30	180	8
6531/11	30	40	180	8
6531/15	100	61	210	12
6531/22	300	80	298	12
6531/24	500	97	325	8
6531/27	800	113	375	8

6541 GLASS FLASKS KJELDAHL, ROUND BOTTOM INTERCHANGEABLE JOINT

Cat. Ref.	Capacity Ml.	Approx O.D. mm.	Hight. mm	Joint	Qty per case
6541/24	500	97	325	24/29	8
6541/27	800	113	375	24/29	8
